Rim straightening machine with lathe Rsm2400

RSM2400 rim correction machines using a lathe

KEMA Quality B.V. / Holland

CE certificate

It is used to correct all types of rims from 10” to 26”.

Dimensions (pallet) RSM2400

Height: 1420 mm

Length: 1200 mm

Width: 800 mm

Gross weight: 320 kg

Engine specifications

Mechanical motor: 0.55 kW / 0.75 HP, 1400 rpm, 3 phase - 1 phase, 220V - 380V

Hydraulic motor: 0.55 kW / 0.75 HP, 900 rpm, 3 phase - 1 phase, 220V - 380V

Noise level: 45 dB

Hydraulic piston force

Total pressure/force = πr² x 160 (working pressure/bar)

Total pressure / force = 3.14 * (3.15 x 3.15) = 31.156 kg

Total pressure / force = 31,156 x 160 = 4 984,96kg

Piston cylinder diameter 63 mm. The radius in centimeters is 3.15 cm.

As shown in the formula above, the RSM2200 rim straightening machine

It produces a force of 5 tons while working.

List of standard equipment

1. 18pcs rim hub rings

2. 1 piece of micrometer

3. 6 pieces of pressure heads

4. 3pcs pressure head accessories

5. 1 piece of lever

6. 1 piece of lathe pen

7. 1pc of upper bracket

8. 1 piece of bottom bracket

9. 4pcs prop pins

10. Flange bolts and nuts
